Chipset |
CPU&2.4G WLAN SOC: MT7621A, 880Mhz; |
5G WLAN: MT7905DA+ MT7975DN; |
2.4G WLAN: MT7905DA+ MT7975DN; |
DRAM/FLASH |
DRAM: 256MB DDR3 SDRAM, FLASH: 16MB SPI Flash |
|
2.4GHz: IEEE802.11ax, IEEE802.11n, IEEE802.11g, IEEE 802.11b; 5.0GHz: IEEE802.11ax, IEEE 802.11ac, IEEE802.11n, IEEE 802.11a; Ethernet: IEEE802.3, IEEE802.3u, IEEE802.3ab; |
Standards |
4G TDD-LTE; FDD-LTE; |
|
5G NR NSA; NR SA |
|
WAN: 1xRJ45, 10/100/1000Mbps |
|
LAN: 2xRJ45, 10/100/1000Mbps |
Interface |
Power: DC12V (±10%)/2A(Max) |
|
Input SIM: NANO SIM Interface |
Buttom |
WPS/Reset Button |
LED |
SYS (blue), Power (red) |
Antenna |
2.4/5G two Antennas, 5G LTE six Antennas |
5G |
3GPP Release 15 NSA/SA operation, Sub-6 GHz |
5G NSA: n41/n78/n79 5G SA: n1 /n28*/n41/n78/n79 |
LTE |
LTE-FDD: B1/B2/B3/B5/B7/B8 LTE-TDD: B34/B38/B39/B40/B41 |
WCDMA |
B1/B2/B5/B8 |
Working Modes |
Router Mode, 5G Mode |
Wireless Security |
Open, WPA2-PSK, WPA3-PSK, WPA-PSK/WPA2-PSK, WPA2-PSK/WPA3-PSK |
Connection Type |
5G Connection, PPPOE Connection, Static IP Connection, DHCP Connection |
Working Environment |
Operating Temperature: 0℃~40℃ (32℉~104℉) |
Storage Temperature: -40℃~70℃ (-40℉~158℉) |
Operating Humidity: 10%~90% non-condensing |
Storage Humidity: 5%~90% non-condensing |
