Feature
● Low insertion loss, low PDL.
● Good channel-to-channel uniformity.
● Wide operating wavelength from 1260~1650nm.
● Using adaptor as an input port.
● Input and output cable: OD2.0mm, good mechanical performance, convenient for connector assembly.
Parameter |
1x2 |
2x2 |
1x4 |
2x4 |
1x8 |
2x8 |
1x16 |
2x16 |
1x32 |
2x32 |
1x64 |
2x64 |
Operating wavelength(nm) |
1260 ~ 1650 |
Fiber type |
G652D/G657A1/G657A2 |
Insertion Loss(dB) |
4 |
4 .2 |
7 .2 |
7 .4 |
10 .5 |
10 .8 |
13 .7 |
14 |
17 |
17 .5 |
20 .6 |
21 |
Uniformity(dB) |
0 .4 |
1 |
0 .6 |
1 .5 |
0 .8 |
1 .5 |
1 .2 |
2 |
1 .5 |
2 |
2 |
2 .5 |
Return Loss(dB) |
55 |
55 |
55 |
55 |
55 |
55 |
PDL(dB ) |
0 .2 |
0 .3 |
0 .2 |
0 .3 |
0 .2 |
0 .3 |
0 .3 |
0 .3 |
0 .3 |
0 .3 |
0 .35 |
0 .5 |
Directivity(dB) |
55 |
55 |
55 |
55 |
55 |
55 |
Temperature Stability (-40~85℃)(dB) |
0 .5 |
0 .5 |
0 .5 |
0 .5 |
0 .5 |
0 .5 |
Operating Temperature(℃) |
-25~70 |
Storage Temperature(℃) |
-25~70 |
ABS box dimension (LxWxH)mm |
100x80x10 |
100x80x10 |
100x80x10 |
20x80x18 |
140x115x18 |
140x115x18 |
Notes: Add an additional 0 .3dB loss per connector.
